Vehicle parameters | Total length (mm) | 6630 | Engine parameters | Engine model | CR4N29C6A |
Overall width (mm) | 2280 | ||||
Total height (mm) | 2870/ 2930/3040 | Engine factory | Chongqing Kairui | ||
Interior height of the compartment (mm) | 1900 | location/fuel | Pre/CNG | ||
Wheelbase (mm) | 3650 | Engine type | Four-cylinder in-line, water-cooled | ||
Front suspension/rear suspension (mm) | 940/2040 | Maximum power (kw) | 98kw / 2800rpm | ||
Approach/departure angle (º) | 22/13 | Maximum torque (Nm/rpm) | 360 /1400~ 2400rpm | ||
First step pedal height | 380 | Displacement (ml) | 2892 | ||
Factory-set maximum total mass (kg) | 7000 | Emission Standards | China VI | ||
Rated number of passengers (person) | 24-25 | Vehicle announcement and batch | 326 batches | ||
Maximum speed (km/h) | 100 | Product grade and batch/number of people | 43 batches/25 | ||
Luggage compartment volume (m3) | -- | National environmental protection catalog and batches | Yes | ||
Front/rear track (mm) | 1810/1670 | Fuel Consumption Test Batch | Operating passenger cars up to the standard: none | ||
Project | Standard configuration | Optional configuration | |||
Chassis parameters and configuration | Chassis model | GP6570KS6TN | |||
Gearbox | 6DS50T Shaanxi Fast Gearbox | ||||
Clutch | Diaphragm spring Ф325, clutch assist | ||||
Front axle | Dana axle (2.3T) 16" disc brake | lake axle | |||
Rear axle | Dana axle (4.5T) 16" disc brake | lake axle | |||
Suspension | Number of leaf springs (front/rear), front 9/rear 11 | Rear stabilizer bar | |||
Turn to | Power steering | ||||
Brake | Air brake, dryer, exhaust brake, ESC+ABS | 1. The slope exceeds 8.5 degrees 2. The slope is 5-8.5 degrees and the brakes are frequent for more than 2 kilometers 3. The slope exceeds 5 degrees, the continuous distance exceeds 6 kilometers, and the speed exceeds 45KM/h If one of the above conditions is met, a retarder is required. | |||
Cylinder | 140L (left side) + 205L winding bottle (under the rear compartment) | ||||
Tire | 205/75R17.5 , tire pressure monitoring | ||||
Battery/generator | N100 maintenance-free × 2/28V/110A | 6-QW-120MF | |||
Other | Copper water tank | Condenser, centralized lubrication, frame reinforcement (including side beams) | |||
Body main assembly | Body structure | non load bearing | |||
Interior | Ordinary interior, left inner luggage rack, right inner armrest | Air-conditioned interior, right inner luggage rack, left inner armrest, front horizontal armrest | |||
Doors and door pumps | Pneumatic folding door (emergency switch for passenger door inside, outside and near the driver), driver's door limit card slot | Electric folding door, pneumatic swing door | |||
Side window | The driver's window is a horse-riding side window, the first piece on the left and the fourth piece on the right are windows in the window (emergency windows), and the rest are sliding windows, the color is F green | Fully enclosed or partially window-in-window structure; the driver's window is hollow and push-pull | |||
Windshield | Front windshield laminated glass, rear windshield tempered glass | ||||
Rear view system | Manual reversing mirror, interior rearview mirror | Imitation rod-style rearview mirror | |||
Air Conditioning System | --- | Overhead air conditioner, 14KW | |||
Heating system | --- | Simple plumbing (with two forced radiators), optional wall-mounted plumbing | |||
Defroster | Shift defroster 24V, 130W | Shift 170W | |||
Audiovisual system | MP3 player | MP3 player with U disk, optional SD card, MP5 system, 15〞/17〞color display | |||
Satellite positioning system | Beidou satellite positioning driving recorder has storage and upload function (dual 32GSD card) 5 probes + 7-inch LCD display (1, Monitor the driver, 2, Monitor the passenger door, 3, Monitor the passenger area from front to back, 4, Monitor the road ahead, 5. Reversing monitoring) | Optional printing function. | |||
Lamps | The front and rear are combined lamps, the electric adjustment device for the low beam height of the headlights, and the high-mounted brake lights | ||||
Wiper | Scraping type electric wiper | ||||
Hatch | Battery access door, air filter access door, left cylinder access door | ||||
Seat | 2+2 layout, 25 seats, ordinary seats (seats next to the aisle with armrests), the driver's seat can be adjusted up and down | Mid-range seat (pull armrest) | |||
Paint | Domestic plain paint | Metallic paint
| |||
Other | The engine speed limit is 99km/h; ordinary floor leather (square grid), flat floor, no sinking of the rear cabin, half-width roll-type sunshade, 2 fire extinguishers (2Kg), 5 safety hammers, 3 sets of rear windshield and left and right Emergency window automatic glass breaker , seat belts for the whole car (partly three-point type), DC816A sunroof, air horn, electric fan, mechanical power-off switch, alarms for the seats of the whole car (sound and light alarm for the driver’s seat), headrests for rear seats Detachable, Manual and automatic integrated fire extinguisher in the engine compartment, luggage restraint device in the rear compartment, boarding handrail, gas leakage alarm device, electronic clock, CAN bus ECU, floor pads under the clutch pedal, and aluminum plate on the footrest under the driver | Engine preheating connection, high and low floor, quartz sand floor leather, aluminum pattern plate or iron pattern plate or iron wood floor, rear compartment sinking, folding side curtains, full-width roller sunshade, aisle carpet, water dispenser, remote control lock , simple megaphone, electronic station announcer, coin-operated machine (manual, electric), and the state of the battery in the warehouse is equipped with a manual fire extinguisher as standard. | |||
