High Quality Isuzu M600 Manual 4x2 Drive New Diesel Refrigerated Container Box Long Refrigerator Trucks

Modification plant

Product features

Exuberance shows

Product parameters

High Quality ISUZU M600 Manual 4x2 Drive New Diesel Refrigerated Container Box Long Refrigerator Trucks



Vehicle nameIsuzu M600
Vehicle size (MM)5995*2270*2980
Body size (MM)4075*2060*1861
volume15.6
Wheelbase (MM)3360
Displacement horse-power3.0L/120
Chassis configuration

7.00R16 8PR tires, 6-speed gearbox, air conditioning, steering assistance,

 ABS, oil brake, central locking, electric glass

Body configuration (customizable)

1, refrigerated truck box is the use of international general sandwich technology +our factory patented wood technology

(keel connection inlaid into environmental protection waterproof wood for heat preservation and corrosion resistance),

bridge insulation technology! The insulation effect reaches the national A-class standard.

2, the box board is made of galvanized pipe skeleton and environmental protection waterproof wood molding, the

middle 8CM insulation board filled, thickened glass steel, the outer frame is made of 304 stainless steel, thickened

aluminum profile edge, 27 stainless steel door lock,accessories, the box splicing out without glue without gaps,

cooling speed, slow temperature, insulation effect is good, the door with bevel edge, The auxiliary beam is a one-time

folding of high-strength steel beam steel, and is locked with a pressure plate. The side protection net and the rear

bumper are one-time formed

3, the refrigerated truck factory production line is the world's most advanced 20 meters large composite plate production

line, the machine automatic cleaning before the production of plate table, to ensure that the press machine a pressing

molding, its production equipment and technology are leading the industry standard, the box appearance is beautiful,

the overall weight is light, high strength, no leakage characteristics, the box is durable, high insulation effect,

The insulation effect reaches the national A-class standard.

Refrigeration unit selection

According to the use :

1 Choose imported refrigeration units or domestic.

2 Select independent or non-independent refrigeration units.

3 Select a system with or without heating.

4 Select a system with or without power backup
