Product features
Why choose us?
We are mainly engaged in CBU, Auto parts, SKD,CKD project and ONE STOP Integrated Solutions SERVICE in Auto industry professionally.
Exuberance shows
Product parameters
| Model | Isuzu 600P NKR (SCR) | Isuzu 600P NKR (PF) | |
| Cabin model number | QL1070A5FAY L10EA | QL1070A5FAY L15EA | |
| Drive Type | 4X2 | 4X2 | |
| Wheelbase | Length (mm) | 2765 | 2765 |
| Cabin chassis Weight | GVW (kg) | 6720 | 6720 |
| Curb Weight (kg) | 2050 | 2050 | |
| Overall size | Length*Width*Height (mm) | 5230x1880x2200 | 5230x1880x2200 |
| Box Size | Length*Width*Height (mm) | 3600×1790×400 | 3600×1790×400 |
| Cab | Double/Single | single | single |
| Driver & Passenger | 2 | 2 | |
| Engine | Model | Isuzu 4KH1CN5HS | Isuzu 4KH1-TCG51 |
| Emission Standard | Euro 5 | Euro 5 | |
| Displacement (L) | 2.999 | 2.999 | |
| Rated Power (KW) | 96kw | 85kw | |
| Type | 4 Cylinders in line, high presure, electrical common-rail diesel fuel injection system, water cooling , turbo charging, inter cooling. | ||
| Transmission | Manual | ||
| Gear | MSB 5 Forward + 1 Reverse | ||
| Wheel Distance（mm) | Front | 1540 | 1540 |
| Rear | 1425 | 1425 | |
| Axle payload（kg) | Front Axle | 2300 | 2300 |
| Rear Axle | 4420 | 4420 | |
| Max. Speed (km/h) | 110 | 110 | |
| Brake System | Air /Oil | Oil | Oil |
| Standard Configurations | Tire | 7.00R16 | 7.00R16 |
| Power Steering | ● | ● | |
| Radio | ● | ● | |
| A/C | ● | ● | |
| ABS | ● | ● | |
