Product features
Why choose us?
We are mainly engaged in CBU, Auto parts, SKD,CKD project and ONE STOP Integrated Solutions SERVICE in Auto industry professionally.
Exuberance shows
Product parameters
| Cabin model | Isuzu 700P NPR (DPF) | Isuzu 700P NPR (DPF) | Isuzu 700P NPR (DPF) | |
| Cabin model number | QL10909KARY P404-2 | QL10909LARY P403-2 | QL10909MAR1Y P441-2 | |
| Drive Type | 4X2 | 4X2 | 4X2 | |
| Wheelbase | Length (mm) | 3815 | 4175 | 4475 |
| Cabin chassis Weight | GVW (kg) | 9390 | 9410 | 9056 |
| Curb Weight (kg) | 2970 | 2980 | 3040 | |
| Overall size | Length*Width*Height (mm) | 6980X2170X2350 | 7430X2170X2350 | 7930X2170X2350 |
| Box Size | Length*Width*Height (mm) | 5070X2279X2215 | 5512X2250X2215 | 6212X2250X2215 |
| Cab | Double/Single | single | ||
| Driver & Passenger | 3 | |||
| Engine | Model | Isuzu 4HK1-TCG40 | ||
| Emission Standard | Euro IV | |||
| Displacement (L) | 5.193 | |||
| Rated Power (KW) | 139 | |||
| Type | 4 Cylinders in line, high presure, electrical common-rail diesel fuel injection system, water cooling , turbo charging, inter cooling. | |||
| Transmission | Manual | |||
| Gear | MLD-6Q 6 Forward + 1 Reverse | |||
| Wheel Distance（mm) | Front | 1680 | 1680 | 1680 |
| Rear | 1650 | 1650 | 1650 | |
| Max. Speed (km/h) | 110 | 110 | 110 | |
| Brake System | Air /Oil | Oil | Oil | Oil |
| Standard Configurations | Tire | 8.25-16 | 8.25-16 | 8.25-16 |
| Power Steering | ● | ● | ● | |
| Radio | ● | ● | ● | |
| A/C | ● | ● | ● | |
| ABS | ● | ● | ● | |
| Side Open door | ○ | ○ | ○ | |
| Cooler model | Carriier C400 | |||
| Box material | Inside and outside is FRP, the bottome plate is Aluminum Polyurethane Insulation | |||
