SPECIFICATIONS
The Isuzu 100P Chassis: a sturdy base for commercial vehicle construction. Equipped with Isuzu’s renowned diesel engine, it offers consistent performance and a 3.5-ton load capacity. Ideal for customizations—whether refrigerated vans, freight trucks, or service vehicles. Designed for fuel efficiency, minimal upkeep, and smooth compatibility with your business requirements. Crafted to perform, crafted to endure.
| Work capacity: | 2-5tons |
| Engine power: | 120HP |
| Engine type: | 4KH1CN6LB |
| Axle drive: | 4X2,LHD |
| Gear box: | Manual MSB-5 |
| Remarks: | Isuzu 100P light truck chassis |
DIMENSIONS
The Isuzu 100P Chassis establishes the standard for commercial vehicle dependability, boasting a strong Isuzu 4KH1-CN6LB 3.0-liter turbo-diesel engine that generates 120 horsepower and 375 Newton-meters of torque. Mated to a 5-speed manual gearbox (MSB-5), it guarantees smooth power transfer and fuel economy whether traveling through city streets or rural roads. Its ladder-style frame (700mm in width) and multi-leaf spring suspension—with 8 leaves at the front and 6+5 leaves at the rear—enable a gross vehicle weight (GVW) capacity of 7.3 tons, while the 4.8-ton rear axle is built to manage heavy loads without compromising stability. Safety is a key focus, with anti-lock braking system (ABS), hydraulic drum brakes, and a vacuum servo system working together to deliver precise control even when fully loaded. The 7.00R16 radial tires (8-ply rating) provide excellent traction and toughness across various surfaces, and the 100-liter fuel tank reduces the need for frequent refueling, maximizing operational time. Designed to meet Euro V emissions standards (using DPF and SCR technology), it strikes a balance between performance and environmental care, making it perfect for industries that require eco-conscious operations. Fleet operators will appreciate the modular design, which simplifies the addition of refrigeration units, cargo containers, or tipper attachments. Backed by Isuzu’s worldwide engineering expertise and round-the-clock after-sales support, this chassis blends Japanese manufacturing precision with low maintenance expenses, ensuring reliable service for years to come.
| General information | Chassis model | 100p light truck chassis | ||
| Wheelbase(mm) | 3360 | |||
| Drive Type | 4X2 | |||
| GVW (kg) | 7300 | |||
| Curb Weight (kg) | 2250 | |||
| Cabin | single | |||
| Driver and Passenger | 2 | |||
| Engine | Model | 4KH1CN6LB | ||
| Type | 4 Cylinders in line, high presure, electrical common-rail diesel fuel injection system, water cooling , turbo charging, inter cooling. | |||
| Emission Standard | Euro VI | |||
| Displacement (L) | 2.999 | |||
| Rated Power (kw/rpm) | 88kw | |||
| Max. Torque (N.m/rpm) | 290N.m | |||
| Transmission | Model | Manual,MSB | ||
| 5 Forward + 1 Reverse | ||||
| Brake System | Service brake | Double circuit, air drive | ||
| Brake(Oil/Air) | air brake | |||
| Parking brake | Central drum brake | |||
| standard Configuration | Tires | 7.00R16LT 14PR,7.00-16LT 14PR | ||
| Power steering |  ● | |||
| Radio | ● | |||
| ABS | ● | |||
| A/C | ● | |||
| Tilted cabin | ● | |||
| Exhuast brake | ● | |||
| Option configuration | Central lock | ● | ||
| Electric window | ● | |||
| Deflector | ● | |||
| Dimensions | Length OAL (mm) | 5900 | ||
| Width OW (mm) | 1880 | |||
| Height OH (mm) | 2200 | |||
| Front Tread AW (mm) | 1504 | |||
| Rear Tread CW (mm) | 1425 | |||
| 1. ● means standard configuration. ○ means option configurtaion | ||||
| 2. All above information is for reference only, and will be updated timely without notice; | ||||
| 3. The listed models are part of the full products range, any special request will be available on request. | ||||
The Isuzu 100P Chassis reimagines versatility, serving a wide range of industries from logistics to construction. Its 3360mm wheelbase and compact 1860mm width allow for nimble movement in tight spaces, making it the top pick for urban delivery fleets. The 4.275m cargo area (1.79m wide) can handle 3.5-ton loads, while customizable setups—like refrigerated vans (with thermal insulation) or dump trucks (equipped with hydraulic lifting systems)—address specialized requirements. In construction and agriculture, this chassis stands out thanks to its heavy-duty rear axle (4.8 tons) and reinforced subframe (made of manganese steel), ensuring dependable transport of equipment and materials. The 4JB1-CN engine (98 HP, 220 Nm torque) provides ideal power for off-road work, and the 5-speed transmission enables precise gear shifting on steep slopes. For public services, the 100P Chassis can be converted into water sprinklers (with a 5000L capacity) and sanitation vehicles, taking advantage of its low noise and vibration levels to suit urban settings. Fleet managers gain from Isuzu’s 40+ years of experience in China, which includes a nationwide network of service centers and extended warranty plans (up to 5 years/150,000 km). Isuzu’s Intelligent Fuel-Saving System optimizes fuel efficiency, cutting operational costs by as much as 15% compared to rival models. The ergonomic cab—featuring air conditioning and power steering—boosts driver comfort, while the 360° visibility (via a multi-mirror configuration) reduces blind spots for safer operations. From last-mile delivery to heavy-duty projects, the Isuzu 100P Chassis is more than just a platform—it’s a forward-thinking investment in long-term productivity.
