Body application
SPECIFICATIONS
The Qingling Isuzu TAGA H Pickup combines tough durability with flexible functionality. Under the hood, its 3.0T turbo diesel engine churns out 105kW of power and 320N·m of torque, making light work of 1,000kg loads and rough off-road terrain thanks to its 4WD system. A sturdy steel chassis and 215mm ground clearance further enhance its ability to withstand harsh conditions. Inside the cabin, a 10-inch touchscreen display and comfortable seating strike a perfect balance between workday practicality and adventure-ready comfort. It’s your go-to, all-purpose companion for tackling tough jobs and embarking on getaways alike.
| Engine power: | 105HP |
| Engine type: | 4KH1CT6H1 |
| Axle drive: | 4X2/4x4,LHD |
| Gear box: | MUA-5G |
| Remarks: | Qingling Isuzu TAGA H Pickup |
DIMENSIONS
The Qingling Isuzu TAGA H is built to conquer the hardest challenges, beginning with its 3.0T turbocharged diesel engine. Producing 105kW of power and 320N·m of torque, it easily manages heavy weights—up to 1,000kg—and steep hills, making it perfect for building sites or distant delivery work.
Its smart 4WD system with shift-on-the-fly technology allows drivers to change between 2WD and 4WD in an instant, while the rear differential lock provides grip on muddy, gravelly, or snowy surfaces.
Based on a 3H high-strength steel frame (70% high-tensile steel), it has 215mm of ground clearance and strengthened undercarriage protection, keeping important parts safe from rocks and other debris.
The 6-speed manual or automatic gearbox optimizes how power is sent, balancing tough performance with fuel economy—it uses just 8.2L per 100km on highways, which is great for long-distance jobs that don't need frequent stops to refuel.
| TAGA Series | Elegant Version | Luxury Version | Super Luxury Version | |
| Drive type | 4X4 | 4X4 | 4X4 | |
| Wheelbase | 3096 | 3096 | 3096 | |
| Curb weight | 2140 | 2140 | 2140 | |
| GVW | 3265 | 3265 | 3265 | |
| Cargo compartment size | 1485X1540X480 | 1485X1540X480 | 1485X1540X480 | |
| Overall size | 5382x1877x1830 | 5382x1877x1830 | 5382x1877x1830 | |
| Engine | 4KH1CT6H1(Remove DPF) | |||
| Rated power (kW) | 105 | 105 | 105 | |
| Maximum net torque Nm | 310 | 310 | 310 | |
| Displacement (l) | 2999 mL | 2999 mL | 2999 mL | |
| Arrangement method | Inline | Inline | Inline | |
| Intake method | Turbocharged | Turbocharged | Turbocharged | |
| Gearbox | MUA-5G | |||
| Gearbox ratio | 4.008/2.301/1.427/1.000/0.828/R3.651 | |||
| Main reducer speed ratio | 3.55 | |||
| Security configuration | Main and Passenger Airbags | Main ●/Vice ● | Main ●/Vice ● | Main ●/Vice ● |
| Force-limiting seat belt/seat belt not fastened reminder | Main ●/Vice ● | Main ●/Vice ● | Main ●/Vice ● | |
| Front seat belt height adjustment/rear seat belt (three-point) | ● | ● | ● | |
| Remote control key, central lock in the car, automatic lock when driving, door open warning, child safety lock, front door glass automatic lift function | ● | ● | ● | |
| Tire pressure monitoring system | ● | ● | ● | |
| Front disc rear drum | ● | - | - | |
| Front and rear disc | - | ● | ● | |
| Brake shoe wear alarm | ● | ● | ● | |
| Engine electronic anti-theft | - | ● | ● | |
| Rear window electric heating defrosting | - | - | ● | |
| Manipulation configuration | Keyless entry, one-button start system | - | - | ● |
| ABS anti-lock brake | ● | ● | ● | |
| Four-wheel drive electronic conversion | ● | ● | ● | |
| Brake force distribution EBD | ● | ● | ● | |
| Vehicle Stability Control (ESC) | - | ● | ● | |
| 360 panoramic images, lane departure, driving records | - | - | ● | |
| Cruise control | ● | ● | ● | |
| Internal configuration | Soft instrument panel, soft door panel | ● | ● | ● |
| Adjustable multifunction steering wheel | ● | ● | ● | |
| Steering wheel material | PU foam | PU foam | ●PU foam/O leather | |
| Full-screen liquid meter,instrument panel backlight brightness adjustable, driving computer display | ● | ● | ● | |
| Remote control fuel tank lid lock | ● | ● | ● | |
| Parking radar | Front- /Back● | Front- /Back● | Front- /Back● | |
| Portable ashtray | ● | ● | ● | |
| Chrome-plated inner handle | ● | ● | ● | |
| Large volume storage space (can hold 1.5L mineral water | ● | ● | ● | |
| Rear car power supply | ● | ● | ● | |
| Seat configuration | Seat Material/Color | fabric/black | faux leather/black | faux leather/black |
| Manually adjustable front seats | ● | - | - | |
| Ten-item electric adjustable driver's seat / eight-item electric adjustable co-pilot seat | - | ● | ● | |
| Driver's seat lumbar support | - | ● | ● | |
| Rear seat down method | Four or six down | Four or six down | Four or six down | |
| Rear center armrest | ● | ● | ● | |
| Multimedia configuration | Intelligent Interconnection System (Internet of Vehicles) | - | o | o |
| MP5 (high configuration version): Real-time color large screen, radio, GPS+BD dual-mode navigation, USB, Bluetooth/car phone, mobile phone interconnection, mobile phone charging, voice recognition, reversing image, 360 panoramic image | - | - | ● | |
| MP5 (middle version): Real-time color large screen, radio, USB, Bluetooth/car phone, mobile phone interconnection, mobile phone charging | ● | ● | - | |
| 360 panoramic image | - | - | ● | |
| Number of speakers | 4 | 4 | 6 | |
| Lighting configuration | Lens low /high beam light | halogen | halogen | halogen |
| C-shaped LED daytime running lights | ● | ● | ● | |
| Turning auxiliary lights (turning auxiliary lights and front fog lights are optional at the same time) | - | ● | ● | |
| Front/Rear Fog Lights | Front- /Back● | Front ●/Back ● | Front ●/Back ● | |
| Front and rear reading lights | ● | ● | ● | |
| High mount brake light | ● | ● | ● | |
| Glass/mirror | Electric windows | Front ●/Back ● | Front ●/Back ● | Front ●/Back ● |
| Electric rearview mirror with electric folding heating/with side turn signal | ● | ● | ● | |
| Glasses case | ● | ● | ● | |
| Sun visor vanity mirror | Left ●/Right ● | Left ●/Right ● | Left ●/Right ● | |
| Air Conditioning System | Rear air outlet | - | ● | ● |
| Automatic air conditioner | - | ● | ● | |
| External configuration | Cargo box treasure or spray anti-wear layer | o | o | ● |
| Non-slip side steps | o | ● | ● | |
| Cargo box roll cage/external independent rope hook/pedal type rear bumper | ● | ● | ● | |
| Body-colored door handles/chrome-plated door handles | ●/o | ●/o | ●/o | |
| Headlight trim | paint | paint | paint | |
| Automatic induction intermittent adjustable wiper | - | ● | ● | |
| Tire specifications | 245/70R18 | 245/70R20 | 245/70R22 | |
| Aluminum alloy steel ring and decorative cover | ● | ● | ● | |
| Tank | Plastic fuel tank 77L | Plastic fuel tank 79L | Plastic fuel tank 81L | |
| Engine cover | Fully enclosed decorative cover | - | ● | ● |
| Front trim cover | ● | ● | ● | |
| Air strut | ● | ● | ● | |
| Interior color | Dashboard | black | black | black |
| Dashboard right trim panel | black | black | Black o dark brown faux leather covering | |
| Door handle | Black faux leather upholstery | Black faux leather upholstery | Black faux leather upholstery | |
| Door trim cover/door trim strip | black/chrome | black/chrome | black/chrome | |
