4KH1CN5LS
Body application
SPECIFICATIONS
wheelbase(mm) | 3360 | |
Drive Type | 4x2 | |
Weight | GVW(kg) | 4495 |
Curb Weight(kg) | 2565 | |
Payload(kg) | 1735 | |
Overall | Length(mm) | 5995 |
Width(mm) | 2160 | |
Height(mm) | 2350 | |
Cab | Double/Single | Single |
Driver & Passenger | 1+2 | |
Cargo Box | Length(mm) | 4205 |
Length（ft) | 14 | |
Width(mm) | 2050 | |
Height(mm) | 380 | |
Engine | Model | 4KH1CN5LS |
Type | 4 Cylinders in line, high presure, electrical common-rail diesel fuel injection system, water cooling, turbo charging, inter cooling. | |
Emission Standard | EURO V | |
Displacement(L) | 2.999 | |
Rated Power(kw/rpm) | 72/3400 | |
Max.Torque(N.m/rpm) | 220/1700 | |
Transmission | MSB | |
Gear | 5 Forward+1 Reverse | |
DIMENSIONS
